Vision Swing Handle RC2 for profile cylinder
Index Code:1-004.04
Low profile swing handle used for latching systems with a control mechanism and flat rods. Approved according to the anti-vandal classification RC2. Optional saw protection available for protection beyond RC2 requirements.
It is used with a 40 mm profile cylinder (ordered separately). Equipped with sliding dust cover and sealed to IP66.
Download PDF | Product Data Sheet |
Dish | Zinc die cast, black coated |
---|---|
Handle | Zinc die cast, black coated |
Pivot shaft | Stainless steel 316 |
Dust cover | Glass fibre reinforced polyamide (PA6GF30) |
O-ring | NBR |
