Adjustable Roller Cam
Index Code:2-486
Adjustable roller cam that can be assembled on all quarter-turn latches for combi cut-out including L-handles, T-handles and knobs. Available both for latches requiring cam with projection and for latches requiring cams without projection. Provides 48 mm adjustability and between 4 – 52 mm for latches with 18 mm housing depth. Cam is secured at chosen grip range with a set-screw.
Both set-screw and screw to attach the adjustable roller cam to the latch are supplied as Phillips head screws.
| Download PDF | Product Data Sheet |
| Cam | Zinc die cast, zinc plated |
|---|---|
| Roller | Glass fibre reinforced polyamide (PA6GF30) |
| Screw | Steel, zinc plated |
| Choose CAD format here:
To download CAD-Files for this product |
| Download here: |
To download CAD-files, you need an Industrilas account. It only takes a minute.
| Grip Range | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 12 mm housing | 18 mm housing | 30 mm housing | 45 mm housing | 56 mm housing | |||||
| H min | H max | H min | H max | H min | H max | H min | H max | H min | H max |
| 0.0 | 46.5 | 4.0 | 52.5 | 16.0 | 64.5 | 31.0 | 79.5 | 42.0 | 90.5 |
