2-831b |
Vector P Hooked Cam
Index Code:This patented heavy-duty paddle latch is available with left, right or universal grip handle. The latching mechanism securely latch the cam behind the striker and the more force that is placed on the cam – the harder it will engage the striker.
Installed with a mounting bracket or four moulded-in bolts. IP66 water- and dust sealing. Key extraction: open/closed
Available with the inside release safety feature. This enables opening the latch from the inside even when it is locked.
Download PDF | Product Data Sheet |
Download PDF | Vector P Handle Types |
Adapter for cylinder (internal component) | Glass fibre reinforced polyamide (PA6GF30) |
---|---|
Body | Glass fibre reinforced polyamide (PA6GF30) |
Cam | Glass fibre reinforced polyamide (PA6GF30) |
Cast-in bolts | Steel, zinc plated |
Cylinder | Zinc die cast, stainless steel 304 cap and dust shutter |
Gaskets | Polyurethane |
Handle | Glass fibre reinforced polyamide (PA6GF30) |
Manoeuver arms | Zinc die cast, zinc plated |
Mounting bracket | Steel, zinc plated |
Nut | Steel, zinc plated |
O-ring | NBR |
Striker | Steel, zinc plated |
Notes | The tightening torque of the two nuts for the mounting bracket is 3,0 Nm. The tightening torque of the four nuts for the mould-in bolts is 2,2 Nm. It is important that the four holes made in the cut out for the mould-in bolts are within tolerance, to avoid damage when tightening the M5 nuts. |
---|---|
Standards | IP66 DIN EN 61373 |
Cylinder information | Cylinder with other key codes on request Supplied with two keys |
|
|
|
|
|
|
|
