External Hinge 40x40 mm 180°
Index Code:3-351
Hinge with cast-in bolts and/or countersunk holes. Universal left and right mounting. Opening angle 180°. Nuts or washers are not supplied with the hinge, but may be ordered separately (see part numbers under Related products, Accessories on this page).
| Download PDF | Product Data Sheet |
| Download PDF | Recommended Tightening Torque |
| Cast-in bolts | Stainless steel 303 |
|---|---|
| Hinge | Zinc die cast, black texture powder coated |
| Nut | Steel, zinc plated |
| Pin | Stainless steel 303 |
| Washer | Steel, zinc plated |
| Standards | DIN EN 61373 |
|---|
