Compression Latch
Index Code:Compression latch that closes and tightens with a single continuous half-turn motion. First 90° turn moves the cam 90°, the second 90° turn retracts the cam 6 mm. The latch is supplied assembled and the cam is ordered separately. Available in clockwise and counterclockwise rotation to open or close. The red dot indicates if the latch is closed and compressed, and the green dot indicates if the latch is open and uncompressed. Sealed against dust and water according IP66.
| Download PDF | Product Data Sheet |
| Download PDF | Recommended Tightening Torque |
| Housing | Zinc die cast, chrome plated |
|---|---|
| Insert | Zinc die cast, chrome plated |
| Nut | Zinc die cast, zinc plated |
| Screw and washer | Steel, zinc plated |
| Notes | Other inserts on request. Latch is supplied with screw with mechanical thread lock. |
|---|---|
| Standards | IP66 |
