Compression Latch 21,5 mm
Index Code:2-130
Compression latch with 6 mm compression of profiles. When closing, the first 90° turn of the key moves the cam 90° to the closed position. Tighten the compression by turning an additional four revolutions with the key. To decompress, turn the key four revolutions in the opposite direction.
The latch is supplied fully assembled.
Measurements for the H-dimension in the table below describes the cam in the compressed position.
| Download PDF | Product Data Sheet |
| Download PDF | Recommended Tightening Torque |
| Cam | Stainless steel 304 |
|---|---|
| Housing | Zinc die cast, zinc plated |
| Insert | Brass, nickel plated |
| Nut | Brass, zinc plated |
| Spring | Stainless steel 304 |
