Handle rotation 90° in both directionsOpening angle of hinges, applicable angle shown in numbers

Round Rods for adapters 15 mm rollers (R) SS 304

Index Code:
2-541

Round Ø 8 mm rod with 15 mm roller, for handles and latches with multi-point cams. The length L in the drawing is the total length from the flat end to the end of the roller. Rod model R is used with a rod adapter (to be ordered separately). The adapter adds 14 mm to the total length (see drawing).

Download PDF
Product Data Sheet
RivetStainless steel 304
RodStainless steel 304
RollerGlass fibre reinforced polyamide (PA6GF30)
