Handle rotation 90° in both directions

Vector cables

Index Code:
2-745

Clips to attach Vector cables to Vector rotaries and Vector actuator handles are included with the handles and rotaries. Vector cables to connect Vector latchpoints, for example Vector rotary latches, Vector actuators and Vector pull handles. Low friction and tension ensures precise and smooth motion control. The L-shaped end-fittings attach easily and securly to the latch points and actuators. Vector cables are equipped with threads for adjustment on both ends, making it easy to adjust on both latch point and actuator side. Other lengths are available upon request.

Clips to attach Vector cables to Vector rotaries and Vector actuator handles are included with the handles and rotaries.

Download PDF
Product Data Sheet
Download PDF
Recommended Tightening Torque
CableHigh carbon steel
Cable casingPVC
End FittingsZinc die cast
NutSteel, zinc plated
To download CAD-files, you need an Industrilas account. It only takes a minute.
or Create Account
A product number is created by combining the figures in each column (AAAA-BCDDEE-HHHH)
AAAA Type
5280Vector cable
B Material wire
1Steel
C Material cover
1Plastic
DD End-fitting
102 x L-shape, zinc
EE Adjustment threads
102 x 21 mm / M6
HHHH Length L1 mm Length L2 mm
0300300382
0500500582
0700700782
0900900982
120012001282
150015001582
